Large-span inflatable hangar
Inflatable Hangar Tent
Rapidly deployable environmental protection for aircraft, vehicles and other critical assets.
Customizable to specification
- Puncture resistance
- ≥ 1,000 N
- 500 m² model
- 32 × 21 × 8.5 m
- 1,000 m² model
- 58 × 35 × 13.4 m
- Operating temperature
- −43°C to +50°C
Overview
Applications
Storage, Rapid Deployment, Environmental Protection, Critical Asset Protection, On-Site Deployment
Specifications
| Product | Inflatable Hangar Tent |
|---|---|
| Specification | Large-span inflatable hangar |
| Item | Specification |
|---|---|
| Structural Performance | |
| Air Beam Puncture Resistance | ≥ 1000 N |
| 500 m² tent Dimension | 32m (L)*21m (W)*8.5m (H) |
| 1000 m² tent Dimension | 58m (L)*35m (W)*13.4m (H) |
| Environmental Adaptability | |
| Operating Temperature | -43°C to +50°C |
| Storage Temperature | -55°C to +70°C |
| Waterproof Performance | Rainfall ≥ 2 mm/min: No leakage for 3 h; No dripping for 5 h |
| Salt Spray Resistance | 150 h without discolouration, chalking, or cracking; suitable for coastal environments |
| Snow Load Capacity | Withstands 100 mm loose snow accumulation |
| Wind Resistance | ≥ 20.7 m/s (Beaufort Scale 8) |
| Reliability & Durability | |
| Continuous Operation | ≥ 60 days with single inflation |
| Designed Service Life | ≥ 5 years |
Video
Giant Inflatable Hangar Door Open & Close — Seamless Access for Aircraft & Equipment
The inflatable hangar door cycling open and closed, giving aircraft and ground equipment full-width access without a rigid structure.
Only a static thumbnail loads before playback — the YouTube player loads after you select play, subject to the Google Privacy Policy.
Video
Deploying a 450 m² High-Pressure Inflatable Tent — Full Setup & Pack-Down Process
Complete setup and pack-down of a 450 m² high-pressure inflatable tent: ≥1000 N air beams, Beaufort 8 wind rating, and 60+ days of continuous operation on a single inflation.
Only a static thumbnail loads before playback — the YouTube player loads after you select play, subject to the Google Privacy Policy.
Customization
All specifications — including dimensions, materials, coating, colour, and accessories — can be tailored to your project requirements. Flexible MOQ from prototype to full-scale production; standard custom projects take 15–30 days from design confirmation to sample delivery.
